HIOS Torque Tester, 0.1-1.0 Nm / 0.15-9.0 lb·in (HP-10)

HIOS Torque Tester, 0.1-1.0 Nm / 0.15-9.0 lb·in (HP-10)
SKUHIO-01207-00100
Part #HP-10
Barcode–
Country of Origin Japan
$3,222.00
Notify Me

Special order: This is item will not ship immediately. HIOS products typically have a lead time of 1-2 weeks if available at a USA warehouse and 6-8 weeks if not. A representative will follow-up with an accurate ETA.

Current Stock:
(No reviews yet) Write a Review

The HP-10 can be used to make highly accurate torque settings and quickly validate torque tool accuracy. Enable efficient torque management and traceability for your production or service operation with this portable battery operated device.

  • Set torque – calibrate electric screwdrivers and manual torque tools to a fixed torque value
  • Audit torque – verify tools are measuring torque accurately within their claimed range
  • Highly portable – battery operated w/ 2.5 hr battery life
  • Charge via USB-B or with included AC power adapter
  • Highly visible display even in bright environments
  • Display shows the measured torque value and waveform
  • Remote operation possible from an external device – mode and threshold can be set
  • Safe torque control – PASS / Fail function to judge the measured torque value
  • Includes storage case
  • Includes run down fixture (Fidaptor) for electric screwdriver measurement
Specifications
Measurement RangeNm0.015 - 1.000
lb·in0.15 - 9.00
Accuracy±0.5%
Measurement DirectionClockwise
Counter-Clockwise
Data TransferBluetooth (wireless)
USB-B
ModesPEAK - Peak torque
F.PEAK – First peak torque
TR1 – Torque waveform
TR2 – Continuous torque waveform
Power InputAC 100-240V (50/60Hz) @ 0.4A
ChargingUSB-B
AC Power Adapter
Battery life2.5 hrs
Charge Time5 hrs
Run Down FixtureTF6SG-Z (0.15-0.60 Nm)
Dimensions (in)9.0 x 4.3 x 2.0"
Weight (lbs)4.3
