Ko-ken 3/8" Sockets, 6-Point Deep SAE (3300A)

Ko-ken 3/8" Sockets, 6-Point Deep SAE (3300A)

(No reviews yet) Write a Review

Description

Premium Made in Japan 3/8" 6-point deep SAE sockets.

3/8" (9.5mm) square drive
For SAE (inch) fasteners
Deep socket depth: 55-65mm long
6-point FLAT DRIVE® – Designed to guarantee a flat surface contact between the socket and bolt/nut to reduce wear and transmit a higher torque value
Fine tolerances provide a snug, precise fitment on fastener heads

Specifications

MPN		D₂mm	D₁mm	Hmm	Lmm	Weightg
3300A-3/16	3/16	8.3	17.3	6	55	35
3300A-7/32	7/32	8.9	17.3	6.5	55	35
3300A-1/4	1/4	9.9	17.3	7	55	37
3300A-5/16	5/16	12	17.3	9	55	40
3300A-11/32	11/32	12.3	17.3	10	55	41
3300A-3/8	3/8	14	17.3	11	55	46
3300A-7/16	7/16	16	17.2	12	55	51
3300A-1/2	1/2	18	17	14	55	53
3300A-9/16	9/16	20	18	16	55	60
3300A-19/32	19/32	21	20	16	55	74
3300A-5/8	5/8	22	20	17	55	76
3300A-11/16	11/16	23.5	22	18	55	93
3300A-3/4	3/4	25	24	20	55	98
3300A-13/16	13/16	27	26	22	65	126
3300A-7/8	7/8	29	28	23	65	163
3300A-15/16	15/16	31	30	25	65	191

Ko-ken 2300M Socket Technical Drawing

SKU

–

Part Number

–

Barcode

–

Country of Origin

Japan

Socket Type

6-Point

Standard

SAE

Set

Individual
